FSR's 3" Depth Large Open Style Wall Box gives installers a shallow wall option for clean AV and IT device storage behind displays. The PWB-323 is designed for installations where wall depth is limited but cable routing, AC connections, and low-voltage mounting still need to be organized behind the finished wall surface.
Like the 4" version, the PWB-323 supports FSR's open-style wall box accessory platform, including trim rings, covers, AC brackets, and equipment mounting options. It is well suited for schools, offices, meeting rooms, hospitality spaces, and commercial display installations that need a cleaner finished look without exposed cables or devices.
**BABAA and TAA compliance by model, which may vary over time due to changes in legislation and/or manufacturing plans. Be sure to ask for certification at the time of order.
FSR's 3" Depth Large Open Style Wall Box gives installers a shallow wall option for clean AV and IT device storage behind displays. The PWB-323 is designed for installations where wall depth is limited but cable routing, AC connections, and low-voltage mounting still need to be organized behind the finished wall surface.
Like the 4" version, the PWB-323 supports FSR's open-style wall box accessory platform, including trim rings, covers, AC brackets, and equipment mounting options. It is well suited for schools, offices, meeting rooms, hospitality spaces, and commercial display installations that need a cleaner finished look without exposed cables or devices.
**BABAA and TAA compliance by model, which may vary over time due to changes in legislation and/or manufacturing plans. Be sure to ask for certification at the time of order.
The PWB-323 has up to 1 1/4" KO's, flush cable-tie mounts, tri-usage gang openings for AC/AV/IT applications, IPS mounting, and two optional adjustable locking shelves for mounting equipment.
There are also 2 optional internal AC brackets available with 2 or 3 Decora openings that ship with SpikeShield 15-amp receptacles included.
These infrastructure solutions are available in sizes to fit typical wall designs and can be used with or without the decorative trim ring and cover options which are sold separately.
BABAA Compliance
FSR floor, ceiling, table, wall box, and Smart-Way raceway products are Build America Buy America Act (BABAA) compliant. Look for this logo on our website:
TAA Compliance
FSR wall box products meet TAA and BABAA requirements.
*Compliance by model may vary over time due to changes in legislation and/or manufacturing plan. Be sure to ask for certification at the time of order.
IMPORTANT DETAILS 3" PWB-323 Wall Box - Optional Accessories Sold Separately
The PWB-323-TRK Kit includes the 3" back box that has flush cable-tie mounts, triple play mounting openings for AC/AV/IT applications, IPS mounting, and two optional adjustable locking shelves for mounting equipment. There are also 2 optional internal AC brackets available with 2 or 3 Decora openings that ship with SpikeShield™ 15-amp receptacles included.
Also included is a powder coated Trim Ring for dressing the dry-wall opening. This rounded trim ring provides a generous 7/8” overlap.
Cover Sold Separately.
BABAA Compliance
FSR floor, ceiling, table, wall box, and Smart-Way raceway products are Build America Buy America Act (BABAA) compliant. Look for this logo on our website:
TAA Compliance
FSR wall box products meet TAA and BABAA requirements.
*Compliance by model may vary over time due to changes in legislation and/or manufacturing plan. Be sure to ask for certification at the time of order.
IMPORTANT DETAILS Kit consisting of - 3" Full Size Box and Decorative Trim Ring
The PWB-323-ESK kit includes the 3" back box that has flush cable-tie mounts, triple play mounting openings for AC/AV/IT applications, IPS mounting, and two optional adjustable locking shelves for mounting equipment. There are also 2 optional internal AC brackets available for purchse with 2 or 3 Decora openings that ship with SpikeShield™ 15-amp receptacles included.
The two adjustable shelves have a hole pattern that allows for any screw spacing from 3/8” to 11 ¾” including multiple VESA 100 hole pattern locations.
Cover Sold Separately.
BABAA Compliance
FSR floor, ceiling, table, wall box, and Smart-Way raceway products are Build America Buy America Act (BABAA) compliant. Look for this logo on our website:
TAA Compliance
FSR wall box products meet TAA and BABAA requirements.
*Compliance by model may vary over time due to changes in legislation and/or manufacturing plan. Be sure to ask for certification at the time of order.
IMPORTANT DETAILS Kit consisting of - 3" Full Size Box, 2 Equipment Shelves and Finished Trim Ring
Optional Trim Ring sold separately unless PWB-323-TrK is purchased.
BABAA Compliance
FSR floor, ceiling, table, wall box, and Smart-Way raceway products are Build America Buy America Act (BABAA) compliant. Look for this logo on our website:
TAA Compliance
FSR wall box products meet TAA and BABAA requirements.
*Compliance by model may vary over time due to changes in legislation and/or manufacturing plan. Be sure to ask for certification at the time of order.
IMPORTANT DETAILS Decorative Finished Trim Ring - Sold Separately
The PWB-323-CV is an optional powder coated cover with rounded cable exits. The vented cover mounts to the trim ring with four tool-less snap fasteners to allow quick access to the equipment inside.
BABAA Compliance
FSR floor, ceiling, table, wall box, and Smart-Way raceway products are Build America Buy America Act (BABAA) compliant. Look for this logo on our website:
TAA Compliance
FSR wall box products meet TAA and BABAA requirements.
*Compliance by model may vary over time due to changes in legislation and/or manufacturing plan. Be sure to ask for certification at the time of order.
IMPORTANT DETAILS Decorative Cover - Sold Separately
Optional internal AC bracket with 2 Decora SpikeShield 15 Amp Receptacles - Ordered Separately.
BABAA Compliance
FSR floor, ceiling, table, wall box, and Smart-Way raceway products are Build America Buy America Act (BABAA) compliant. Look for this logo on our website:
TAA Compliance
FSR wall box products meet TAA and BABAA requirements.
*Compliance by model may vary over time due to changes in legislation and/or manufacturing plan. Be sure to ask for certification at the time of order.
IMPORTANT DETAILS Can also be used with the PWB-323XL
Optional internal AC Bracket with 3 Decora SpikeShield 15 Amp Receptacle - Ordered Separately.
BABAA Compliance
FSR floor, ceiling, table, wall box, and Smart-Way raceway products are Build America Buy America Act (BABAA) compliant. Look for this logo on our website:
TAA Compliance
FSR wall box products meet TAA and BABAA requirements.
*Compliance by model may vary over time due to changes in legislation and/or manufacturing plan. Be sure to ask for certification at the time of order.
IMPORTANT DETAILS Can also be used with the PWB-323XL
Shelving location and depth can be adjusted as well as mounted in horizontal or vertical orientation.
BABAA Compliance
FSR floor, ceiling, table, wall box, and Smart-Way raceway products are Build America Buy America Act (BABAA) compliant. Look for this logo on our website:
TAA Compliance
FSR wall box products meet TAA and BABAA requirements.
*Compliance by model may vary over time due to changes in legislation and/or manufacturing plan. Be sure to ask for certification at the time of order.
IMPORTANT DETAILS 3" Shelf Kit - 2 Shelves and Side Brackets - Ordered Separately
The PWB-323 has 2 optional internal international brackets available with 2 or 4 socket openings. International sockets are sold separately, see the part chart below for your power needs.
BABAA Compliance
FSR floor, ceiling, table, wall box, and Smart-Way raceway products are Build America Buy America Act (BABAA) compliant. Look for this logo on our website:
TAA Compliance
FSR wall box products meet TAA and BABAA requirements.
*Compliance by model may vary over time due to changes in legislation and/or manufacturing plan. Be sure to ask for certification at the time of order.
Item #
Part #
Description
PWB-323 International Bracket
18593
PWB-323-4E45
International four socket opening bracket for use with four 45mm sockets
International Socket Parts
18356
SOC45-UN
45mm Universal Socket 10 Amp / 250VAC
18357
SOC45-TF
45mm Type F SCHUKO - Europe and Russia 16 Amp / 250VAC
18358
SOC45-TI
45mm Type I - Australia, New Zealand, China and Argentina 10 Amp / 250VAC
18359
SOC45-TG
45mm Type G - UK, Ireland, Malta, Malaysia and Singapore 13 Amp / 250VAC
IMPORTANT DETAILS PWB-323-4E45 international bracket with four 45mm socket openings
The PWB-323 has 2 optional internal international brackets available with 2 or 4 socket openings. International sockets are sold separately, see the part chart below for your power needs.
BABAA Compliance
FSR floor, ceiling, table, wall box, and Smart-Way raceway products are Build America Buy America Act (BABAA) compliant. Look for this logo on our website:
TAA Compliance
FSR wall box products meet TAA and BABAA requirements.
*Compliance by model may vary over time due to changes in legislation and/or manufacturing plan. Be sure to ask for certification at the time of order.
Item #
Part #
Description
PWB-323 International Bracket
18594
PWB-323-2E45
International two socket opening bracket for use with two 45mm sockets
International Socket Parts
18356
SOC45-UN
45mm Universal Socket 10 Amp / 250VAC
18357
SOC45-TF
45mm Type F SCHUKO - Europe and Russia 16 Amp / 250VAC
18358
SOC45-TI
45mm Type I - Australia, New Zealand, China and Argentina 10 Amp / 250VAC
18359
SOC45-TG
45mm Type G - UK, Ireland, Malta, Malaysia and Singapore 13 Amp / 250VAC
IMPORTANT DETAILS PWB-323-2E45 international bracket with two 45mm socket openings
FSR's 3" Depth Large Open Style Wall Box gives installers a shallow wall option for clean AV and IT device storage behind displays. The PWB-323 is designed for installations where wall depth is limited but cable routing, AC connections, and low-voltage mounting still need to be organized behind the finished wall surface.
Like the 4" version, the PWB-323 supports FSR's open-style wall box accessory platform, including trim rings, covers, AC brackets, and equipment mounting options. It is well suited for schools, offices, meeting rooms, hospitality spaces, and commercial display installations that need a cleaner finished look without exposed cables or devices.
**BABAA and TAA compliance by model, which may vary over time due to changes in legislation and/or manufacturing plans. Be sure to ask for certification at the time of order.
IMPORTANT DETAILS White Hinged Door Fits on PWB-320 OR PWB-323
